TAC 300

From tactical shooting to long-range hunting, the TAC series is a great starting point for a custom action.

  • List Price: $
  • $

TAC actions are bead-blasted stainless steel action and will fit most stocks with a Remington 700 action inlet. TAC actions have a factory length mag cut allowing for a factory BDL bottom metal and are available with light, standard, and magnum bolt faces.

Standard Features

Receiver Type: Stiller TAC 300

Receiver Material: 416-R Stainless Steel

Receiver Finish: Glass Media Blasted

Receiver Diameter: 1.35" (Remington 700 Footprint)

Headspace: 0.700” +/- .002”

Breach Thread: 1.0625-16 TPI

Scope Mount Pattern: Stiller Round 8-40 (Savage Rounds)

Bolt Style: Push Feed

Bolt Configuration: One Piece

Bolt Handle: Bent Only

Bolt Knob: Threaded Tac Knob

Bolt Lift Angle: 90 Degree

Bolt Material: 4140 Steel

Bolt Finish: Melonite

Rail: None

Recoil Lug: .187” Straight Lug

Handed: Right or Left

Bolt Faces: Standard (.485) or Magnum (.550)

Magwell: Repeater or Single Shot

Magwell OAL: 3.82”

Action Screw Spacing: 7.35"

Length: 8.70”

Weight with Bolt: 30.8oz

Extractor Type: Mini-16

TAC 300 Configurations

Action Body: 16.3 oz
Bolt Only: 11.5 oz
Body, Bolt, Rail, Recoil Lug, and Trigger Pins: 30.8 oz

Receiver Material: 416R Stainless
Receiver Length: 8.700”
Receiver Diameter: 1.35” Remington 700 Footprint
Headspace: 0.007" +/- .002"
Tenon Threads: 1.0625-16 UN-3B. Threads are made with a single point boring bar and indexed to top center of action. This allows any barrel ever fitted to a Stiller Action to be screwed onto any other Stiller Action without need for re-headspacing or re-indexing.

Bolt Design: One piece fluted on top and sides but not the bottom so that flutes will not interfere with magazine lips. TAC 30, TAC 300, and PREDATOR actions have a slightly swept bolt handle. TAC and PREDATOR actions have a large knob with 5/16 x 24 thread. Aftermarket knobs can be swapped out by user or gunsmith.
Bolt Diameter: 0.007"
Bolt Stop: On side of receiver opposite bolt handle above the stock line
Bolt Throw: 90 degrees
Bolt Material: 4140
Bolt Coating: Black Nitride
Firing Pin: Fluted Stainless Steel, 0.067" diameter tip
Extractor/Ejector: Modified M16 type extractor, Rem 700 style pin ejector
Recoil Lug: 416R Stainless parallel sided or tapered. .187” (Rem 700 standard) or .300” produced in house and surface ground to .0002” tolerance.

product image

Action Weights

Body, Bolt, Rail, Recoil Lug, and Trigger

30.8 oz

Action Body

16.3 oz

Bolt Only

11.5 oz
